11.92 9 STEP 5 Operation Set with Programming Examples
9.3.11 Jump operations
9.3.11 Jump operations
The jump destination for unconditional and conditional jumps is specified symbolically
(maximum of 4 characters): the symbolic parameter of the jump command is identical with the
symbolic address of the statement to be jumped to. When programming, ensure that the
unconditional jump distance is not more than ± 127 words. If should be noted that a STEP 5
statement must not comprise more than one word. Jumps may only be executed within a
block. Jumps extending beyond networks are not allowed.
Operation Description
JU = Jump, unconditional
The unconditional jump will be executed independently of
conditions.
JC = Jump, conditional
The conditional jump will be executed if the result of the
logic operation is 1. If the RLO is 0 the jump will not
be executed and the RLO will be set to 1.
JZ = Jump if accumulator content is zero
The jump will be executed if the accumulator content is zero.
If the accumulator content is not zero the jump will not be
executed. The RLO will not be changed.
JN = Jump if accumulator content is not zero
The jump will be executed if the accumulator content is not
zero. If the accumulator content is zero the jump will not be
executed. The RLO will not be changed.
JP = Jump if accumulator content is positive
The jump will be executed if the accumulator content is
greater than zero. If the accumulator content is zero or
less than zero, the jump will not be executed. The RLO will not
be changed.
JM = Jump if accumulator content is negative
The jump will be executed if the accumulator content is
less than zero. If the accumulator content is zero or greater
than zero, the jump will not be executed. The RLO will not
be changed.
JO = Jump if overflow
The jump will be executed in the event of an overflow. If
there is no overflow, the jump will not be executed. The RLO
will not be changed.
© Siemens AG 1992 All Rights Reserved 6FC5197- AA80 9–37
